NTC Inrush Cl Series

Type	Resistance @ 25°C (Ω) ±25%	Max Steady State Current (Amps RMS)	@120 (VAC Rms)	@240 (VAC Rms)	Max Energy (Joules)
CL-11	0.7	12	2700	675	19.44
CL-21	1.3	8	800	200	5.76
CL-30	2.5	8	6000	1500	43.20
CL-40	5	6	5200	1300	37.44
CL-50	7	5	5000	1250	36.00
CL-60	10	5	5000	1250	36.00
CL-70	16	4	5000	1250	36.00
CL-80	47	3	5000	1250	36.00
CL-90	120	2	5000	1250	36.00
CL-101	0.5	16	4000	1000	28.80
CL-110	10	3.2	600	150	4.32
CL-120	10	1.7	600	150	4.32
CL-130	50	1.6	600	150	4.32
CL-140	50	1.1	600	150	4.32
CL-150	5	4.7	1600	400	11.52
CL-160	5	2.8	1600	400	11.52
CL-170	16	2.7	1600	400	11.52
CL-180	16	1.7	1600	400	11.52
CL-190	25	2.4	800	200	5.76
CL-200	25	1.7	800	200	5.76
CL-210	30	1.5	600	150	4.32

Type	Resistance @ 25°C (Ω) ±25%	Max Steady State Current (Amps RMS)	@120 (VAC Rms)	@240 (VAC Rms)	Max Energy (Joules)
CL-11A	0.7	12	2700	675	19.44
CL-21A	1.3	8	800	200	5.76
CL-30A	2.5	8	6000	1500	43.20
CL-40A	5	6	5200	1300	37.44
CL-50A	7	5	5000	1250	36.00
CL-60A	10	5	5000	1250	36.00
CL-70A	16	4	5000	1250	36.00
CL-80A	47	3	5000	1250	36.00
CL-90A	120	2	5000	1250	36.00
CL-101A	0.5	16	4000	1000	28.80
CL-110A	10	3.2	600	150	4.32
CL-120A	10	1.7	600	150	4.32
CL-130A	50	1.6	600	150	4.32
CL-140A	50	1.1	600	150	4.32
CL-150A	5	4.7	1600	400	11.52
CL-160A	5	2.8	1600	400	11.52
CL-170A	16	2.7	1600	400	11.52
CL-180A	16	1.7	1600	400	11.52
CL-190A	25	2.4	800	200	5.76
CL-200A	25	1.7	800	200	5.76
CL-210A	30	1.5	600	150	4.32

Thermometrics Current Limiters
