The NovaSensor PT2710 piezoresistive sensor die is designed for pressure and temperature measurements using a single chip. When excited by either constant voltage or constant current, a PT2710 pressure sensor produces a differential millivolt output signal directly proportional to the applied pressure. With NovaSensor’s SenStable® process, PT2710 die features excellent long-term stability and repeatability (< 0.1% / year typical). The on-chip temperature sensor powered by constant current allows for high accuracy measurement of temperature and for improvement of pressure measurement accuracy.arity, offset, temperature coefficients and hysteresis.
• Process control systems • Pneumatic Controls • Hydraulic Systems • Biomedical Controls
• Highly reliable, solid state silicon pressure and temperature sensor die • Available in Absolute and Gauge versions • Pressure ranges: 0.36 to 5 psi • Temperature range: -40…150°C • On-chip temperature sensor • Die dimensions (L x W x H): 1.96 mm x 1.63 mm x 0.95 mm with glass pedestal 2.07 mm x 1.72 mm x 0.38 mm without glass pedestal • Flexible bond pads configuration supports multiple wire bonding options • Media Compatibility – Clean dry air, noncorrosive gases and liquids, other fluids compatible with silicon and borosilicate glass
